Eachine EV100 720*540 5.8G 72CH FPV Goggles With Dual Antennas Fan 18650 Battery Case For RC Drone

Description:

Item Name : EV100

Size : 165mm*76mm*30mm
Weight : 221g(with battery 57g and antenna 13g)
Package Weight : 400g

Display

Resolution  : 720*540

FOV : 28° diagonal

IPD : 58-68mm
Ratio : 4:3

Focal length adjusting:  under 400 degree of myopia and hyporopia 150 degree

Specification:

Frequency : 5.8G 5333Mhz-5945Mhz

Sensitivity : <=-93dB

Antenna Impedance : 50Ω

Antenna Gain : 3dBi

Antenna Connector : RP-SMA

Video Formate : NTSC/PAL

Support AV IN/OUT

Support Focal Length/Brightness/Contrast Adjustment

Suport Firmware Upgrading

Power Input : 7.4V

Low Voltage : 6.8V

Battery : 18650 battery case

Charging : USB Cable(not included)

Working Temp. : -10℃-+40℃

Features
Support AV Input and Output( it doesn't support Audio in FPV mode, for the build-in receiver can't receive audio. But in AV-IN mode, the audio is available.)

Support External HDMIto AV Module

Support External DVR module

Single receiver with Dual Antennas, enhance the reception and stable performance.

With Fan, can defog the glasses for good visual experience.

Adjustable focal length,allows pilots under 400 degree myopia view directly via naked eye

Adjustable IPD 58~68mm

Auto Search function, can auto search all frequencies and select the channel of stongest signal.

Has 3 Racing Modes : 4/6/8 pilots. 60-80MHz interval between adjacent channels greatly decrease interference.

Has Debug Mode, requires a corresponding VTX which support pitmode and extra frequency 5300MHz

Package Included

1 x Eachine EV100 5.8G 72CH FPV Goggles

1 x 18650 Battery case

2 x RP-SMA 3dBi Antenna

1 x User Manual
